Converters
SINAMICS V20
SIEMENS SINAMICS V20
Cost-effective, reliable and easy to use - inverter for basic applications
Today, when the industrial production of more and more applications, comes to the fore the need for individual solutions that will automate simple moving processes with minimal requirements. Siemens with its compact inverter SINAMICS V20 offers a simple and cost-effective solution for a given application. SINAMICS V20 is distinguished by its simplicity, fast commissioning, robustness and cost effectiveness. SINAMICS V20 with its four sizes covering the power range 0.12 to 15 kW.
- Easy to install - Easy to use - just thrifty
SINAMICS G130
SINAMICS G130 chassis units have been designed for variable-speed drives in machine building and plant construction.
They have been specially tuned to the requirements of drives with quadratic or constant load characteristics with medium performance requirements without regenerative feedback.
The control accuracy of the sensorless vector control is suitable for most applications, and additional actual speed value encoders are therefore superfluous.
SINAMICS G120
SINAMICS G120 is a modular drive inverter system that comprises various function units. These are essentially:
Control Unit (CU)
Power Module (PM)
The CU controls and monitors the PM and the connected motor in several operating modes that can be selected. It supports communications to a local control as well as to monitoring devices and equipment. The PMs has a power range from 0.37 kW to 250 kW.
SINAMICS G110
SINAMICS G110 is a frequency inverter with basic functions for a variety of industrial variable-speed drive applications. The particularly compact SINAMICS G110 inverter operates with voltage frequency control on single-phase supplies (200 V to 240 V). It is the ideal low-cost frequency inverter solution for the lower power range of the SINAMICS family.
Our automation solution for small hydropower plant
OA-AE1
- cabinet dimensions 2000x1600x600
- PLC S7 300 i S7 1200 Siemens
- HMI 15“ Siemens
- Lot equipment Schneider Electric
- SCADA WinCC Professional
- ComAp relay for the protection and synchronization
- Basler device control initiatives
This is certainly a solution that consists of two cabinets containing equipment and automation equipment for the connection of a generator to the grid.
The system is controlled by a controller 300 Siemens S7 series. Power plant can be operated in three ways: through the panel, push button and via SCADA control room.
All measurements (power, current, voltage) can be permanently archived on a computer that is running the SCADA.
OA-AE2
- cabinet dimensions 1200x800x400
- PLC S7 1200 Siemens
- HMI 6,4“ Siemens
- Lot equipment Schneider Electric
- ComAp relay for the protection and synchronization
This is the solution for more modest applications in the sense that we do not have the option of archiving data, but whatever it contains all the elements necessary for the management of the power plant.
The system manages the S7 controller 1200, which all measured data transferred to the panel.
Management is possible through the panel or using the key. The system can be upgraded to meet the requirements of the client.
